An EFT hoist quote needs measured capacity, lift, beam, runway and clearance information before a trolley model can be shortlisted. Hydromech supplies EFT hoist and torsion-beam trolley configurations in Australia, but the product tables do not confirm suitability for an existing crane or guarantee a standard hook-height gain.

This quotation-focused topic avoids repeating our broader articles about torsion-beam trolley performance and hoist mounting. Buyers can first review the EFT hoist and torsion-beam trolley range and then provide the dimensions needed for project screening.

Why Nominal Capacity Is Not Enough

Two lifting projects with the same rated load can require different arrangements because beam width, runway geometry, height of lift, trolley speed and surrounding obstructions differ. Hook approach, rope path, end clearance, electrical interfaces and service access also affect the usable result.

Hydromech’s EFTMD torsion-trolley product data lists models from 3.2 to 25 tonnes with model-specific lift, speed, wheel and beam information. Those figures are a selection reference, not approval for a particular runway.

What Measurements Should Accompany the Enquiry?

Provide drawings where possible and identify whether dimensions are verified or preliminary:

• Rated load and duty: State the maximum lifted load, operating frequency and relevant lifting process.
• Required lift: Measure the lowest hook position and the highest required load or hook position.
• Beam and runway: Provide beam dimensions, span, rail or trolley arrangement and available structural information.
• Headroom envelope: Show roof, services, machinery and other overhead obstructions.
• Travel and approaches: Define trolley travel, end approaches, operating zone and maintenance access.

Our comparison of foot-mount and side-mount hoist systems explains why mounting position affects the overall crane envelope. It should not be used to select equipment without project dimensions.

Assess Existing-Crane Interfaces Before Changing the Trolley

For a retrofit, include the existing hoist, trolley, bridge and runway details plus photographs and available inspection records. A different arrangement may affect structural, mechanical and electrical interfaces. The responsible project team must confirm design, installation, commissioning and inspection requirements before the equipment returns to service.

Safe Work Australia’s crane duties guidance states that crane risks must be eliminated or minimised so far as is reasonably practicable and that specified inspection and testing work requires competent people. Product supply does not replace those obligations.

For wider procurement context, review our article on factory lifting-system capacity before finalising the project brief.

The enquiry should also state the required controls, power supply and operating environment where known. Indoor, outdoor, dusty, corrosive or high-temperature conditions can change the equipment discussion. Leave unknown items marked for confirmation rather than filling the brief with assumed values.

Also identify whether the request concerns a new crane, a replacement assembly or a retrofit to retained equipment, as each creates different interface questions.

Send the Low-Headroom Crane Dimensions

Use our EFT hoist project enquiry to send the capacity, duty, lift, beam and runway dimensions, headroom sketch, photographs and project timing. We can review the information, identify relevant EFT model data and explain what must be confirmed before a formal equipment selection.
